3.5-inch color display
Portable measurement · Portable configuration
Portable Conductivity Analyzer
A handheld meter and conductivity sensor for field verification, surface water, wastewater, aquaculture, boiler water and laboratory sampling.
0–20000 µS/cmIP67 / IP68>100,000 records
Structured from the supplied technical files
Only values confirmed in the current records are published. Products without a commercial model remain configured products; final range, cell constant, material, interface and accessories are controlled by the project datasheet.
01
Construction and product highlights
IP67 handheld meter and IP68 sensor
USB charging and data export
Automatic recognition of the connected sensor
Rechargeable internal battery
More than 100,000 data records
02
Verified technical specifications
Confirm the expected range, cable length, field environment and whether data export is required.
- Measuring range
- 0–20000 µS/cm (K=1)
- Resolution
- 0.1 µS/cm to 0.01 mS/cm depending on range
- Accuracy / linear error
- ±1.5% or ±2 µS/cm, whichever is greater
- Operating temperature
- 0–50°C, non-freezing
- Protection
- Meter IP67; sensor IP68
- Cable
- 3 m standard; extension available
- Display
- 3.5-inch color display with adjustable backlight
- Data storage
- More than 100,000 records
- Dimensions
- Sensor Ø13.5 × 121 mm; meter 203 × 100 × 43 mm
- Weight
- Sensor <0.1 kg; meter 0.5 kg
03
Recommended applications
Field verification
Portable checks during commissioning and routine inspection.
Surface water
Conductivity measurements at rivers, lakes and sampling points.
Aquaculture
Routine checks in ponds and aquaculture water.
Boiler and process water
Spot-check conductivity in utilities and industrial water systems.
04
Items to confirm
Confirm the expected range, cable length, field environment and whether data export is required.
- 01Minimum, normal and maximum conductivity
- 02Water chemistry, temperature and pressure
- 03Cell constant, wetted material and mounting thread
- 04Cable, power, 4–20 mA or RS485 Modbus
05
Parameter sources
These files support the published data. Third-party company branding in source material is not presented on the public page.
