Eight verified models cover pH, ORP, conductivity, dissolved oxygen, turbidity, suspended solids, chlorophyll-a and blue-green algae
FUNEL portable water analysis platform
PMI800 Series Portable Water Quality Analyzer Platform
One handheld platform covers eight interchangeable measurement options: pH, ORP, conductivity, dissolved oxygen, turbidity, suspended solids, chlorophyll-a and blue-green algae. Each model has its own specifications page and quotation path.
Eight verified models cover pH, ORP, conductivity, dissolved oxygen, turbidity, suspended solids, chlorophyll-a and blue-green algae3.5-inch adjustable-backlight color display with automatic sensor recognition and adaptive reading screenMore than 100,000 stored records with USB export
01
Portable host and parameter sensor
3.5-inch adjustable-backlight color display with automatic sensor recognition and adaptive reading screen
More than 100,000 stored records with USB export
IP67 host powered by four 3.7 V rechargeable lithium batteries
Each model has its documented range, accuracy, sensor construction and protection on a dedicated page
02
Product technical specifications
- Verified measurement options
- pH, ORP, conductivity, dissolved oxygen, turbidity, suspended solids, chlorophyll-a and blue-green algae
- Sensor recognition
- Automatic sensor-type recognition and adaptive reading screen
- Configuration
- Parameter setting and calibration from the handheld host
- Display
- 3.5-inch color display with adjustable backlight
- Power supply
- 4 × 3.7 V rechargeable lithium batteries
- Data storage
- >100,000 records
- Data export
- USB
- Host material
- ABS + PC
- Host protection
- IP67
- Operating temperature
- 0–50°C, non-freezing
- Storage temperature
- −15 to 60°C
- Host size and weight
- 203 × 100 × 43 mm; 0.5 kg
03
Recommended portable measurement tasks
Core electrochemistry
Use for rapid measurements, logged readings and result verification in the real water and field conditions.
Optical field measurement
Use for rapid measurements, logged readings and result verification in the real water and field conditions.
Solids and sludge
Use for rapid measurements, logged readings and result verification in the real water and field conditions.
Algae monitoring
Use for rapid measurements, logged readings and result verification in the real water and field conditions.
04
Confirm the water and sensor before selection
The PMI800 host platform is shared, while the sensor, range, calibration and suitable water differ by model. Standard accessories and order codes are not invented; the complete supply configuration is confirmed during quotation.
- 01Confirm the target parameter and normal/peak range
- 02Confirm the water matrix, turbidity, sludge homogeneity or algae distribution
- 03Confirm field measurement, laboratory verification or online-instrument comparison
- 04Confirm cable, quantity, destination and delivery requirement
05
Technical and quotation documents
The page values are structured from the supplied PMI800 technical files. After confirming the model and use conditions, we can prepare a neutral English datasheet, configuration confirmation and quotation.
Share your project requirement- Neutral English technical datasheet→
- Sensor and host configuration confirmation→
- Calibration and field-use guidance→
- Project quotation→
Contact FUNEL
Tell us what you need to measure.
We will respond with a recommended configuration, supporting documentation and quotation.
