VN-09 Drinking Water Nine-Parameter Test Kit
Model: VN-09
A portable field kit for the nine routine drinking-water checks required for rapid sanitary assessment, combining photometric testing, microbiology incubation and precision titration in one transport case.
VN-09
A portable field kit for the nine routine drinking-water checks required for rapid sanitary assessment, combining photometric testing, microbiology incubation and precision titration in one transport case.
Best for: Rural and small-community drinking water checks, Municipal water supply field inspection, Emergency drinking water assessment.
Specifications
- Test scope: pH, color, turbidity, permanganate index, odor and taste, visible matter, disinfectant residual, colony count, total coliform and E. coli
- Disinfectant options: Free chlorine, total chlorine, chlorine dioxide or ozone according to the selected method
- Optical system: LED-silicon photodiode with integrated scattering and transmission paths
- Reading modes: Concentration, absorbance and transmittance
- Programs: Built-in standard methods with custom curve support
- Display language: English and Chinese
- Data interface: USB Type-C; optional Bluetooth and GPS
- Data storage: Results stored with date and time
- Ingress protection: IP65
- Sample vials: 25 mm, 16 mm and 10 mm
- Main analyzer size: 238 x 103 x 75 mm
- Incubator range: 0-50 C with +/-0.5 C temperature accuracy
- Portable titrator: 0.001 mL aspiration increment and 0.2% full-scale accuracy
- Power: Four AA batteries or USB
Applications
- Rural and small-community drinking water checks
- Municipal water supply field inspection
- Emergency drinking water assessment
- School, clinic and public-facility hygiene monitoring
- Water utility sampling routes
- Public-health and third-party inspection teams
Benefits
- Combines chemical, physical and microbiological checks in one field kit
- Reduces the equipment needed for routine drinking-water inspection
- Bilingual guided operation supports distributed field teams
- Stored results and USB export simplify traceability
- Prefabricated reagents shorten on-site preparation
- Portable case keeps instruments and accessories organized
Frequently asked questions
What does the VN-09 measure?
VN-09 is configured for Test scope: pH, color, turbidity, permanganate index, odor and taste, visible matter, disinfectant residual, colony count, total coliform and E. coli; Disinfectant options: Free chlorine, total chlorine, chlorine dioxide or ozone according to the selected method; Optical system: LED-silicon photodiode with integrated scattering and transmission paths; Reading modes: Concentration, absorbance and transmittance.
Where is the VN-09 used?
Typical applications include Rural and small-community drinking water checks, Municipal water supply field inspection, Emergency drinking water assessment, School, clinic and public-facility hygiene monitoring.
How do I select or order the VN-09?
Send FUNEL your target parameters, measuring range, water type, quantity and application. We will confirm the configuration and provide a quotation and datasheet.
