PUVCOD-900 UV COD Organic Matter Online Analyzer
Model: PUVCOD-900
UV spectral organic matter analyzer for online COD and BOD correlation monitoring in wastewater, surface water, and industrial discharge.
PUVCOD-900
UV spectral organic matter analyzer for online COD and BOD correlation monitoring in wastewater, surface water, and industrial discharge.
Best for: Organic matter monitoring in wastewater treatment process and influent or effluent water quality, Continuous monitoring for surface water, industrial wastewater, and enterprise discharge water, Wastewater treatment applications.
Specifications
- Measurement range: COD calibrated with KHP: 0-2000 mg/L COD (2 mm path); 0-1000 mg/L COD (5 mm path); 0-90 mg/L COD (50 mm path)
- Accuracy: ±5% with KHP standard solution
- Repeatability: ±2% with KHP standard solution
- Resolution: 0.01 mg/L
- Pressure range: ≤0.4 MPa
- Sensor material: SUS316L body for standard version; titanium alloy for seawater version; PUR cable
- Sensor size: 69 x 382 mm (2 mm path); 69 x 385 mm (5 mm path); 69 x 430 mm (50 mm path)
- Sensor weight: 3.2 kg
- Sensor protection: IP68 / NEMA6P
- Power supply: AC 85-500 VAC; DC 9-36 VDC
- Output: 3-channel 4-20 mA
- Relay: Three relays with configurable response parameters
- Communication: MODBUS RS485
- Storage temperature: -15 to 60°C
- Operating temperature: 0-45°C, non-freezing
- Transmitter size: 145 x 125 x 162 mm (L x W x H)
- Transmitter weight: 1.35 kg
- Transmitter protection: IP66 / NEMA4X
- Cable length: 10 m standard cable; extendable to 100 m unless otherwise noted
Applications
- Organic matter monitoring in wastewater treatment process and influent or effluent water quality
- Continuous monitoring for surface water, industrial wastewater, and enterprise discharge water
- Wastewater treatment applications
- Drinking water applications
- Surface water applications
- Industrial process water applications
- Aquaculture applications
- Environmental monitoring applications
Benefits
- 254 nm UV absorbance measurement for organic matter and COD/BOD correlation
- Direct immersion measurement with no sampling or reagent dosing
- Fast response for continuous online monitoring
- Automatic cleaning option reduces maintenance
- Reverse-polarity protection, RS485 protection, data storage, and optional wireless module
Frequently asked questions
What does the PUVCOD-900 measure?
PUVCOD-900 is configured for Measurement range: COD calibrated with KHP: 0-2000 mg/L COD (2 mm path); 0-1000 mg/L COD (5 mm path); 0-90 mg/L COD (50 mm path); Accuracy: ±5% with KHP standard solution; Repeatability: ±2% with KHP standard solution; Resolution: 0.01 mg/L.
Where is the PUVCOD-900 used?
Typical applications include Organic matter monitoring in wastewater treatment process and influent or effluent water quality, Continuous monitoring for surface water, industrial wastewater, and enterprise discharge water, Wastewater treatment applications, Drinking water applications.
How do I select or order the PUVCOD-900?
Send FUNEL your target parameters, measuring range, water type, quantity and application. We will confirm the configuration and provide a quotation and datasheet.
