PUVCOD-600 UV COD Organic Matter Online Analyzer
Model: PUVCOD-600
Compact UV COD analyzer for reagent-free continuous COD/BOD and turbidity monitoring in wastewater and surface water applications.
PUVCOD-600
Compact UV COD analyzer for reagent-free continuous COD/BOD and turbidity monitoring in wastewater and surface water applications.
Best for: Continuous organic load monitoring in wastewater treatment processes, Real-time wastewater quality monitoring at influent, effluent, surface water, and industrial discharge points, Wastewater treatment applications.
Specifications
- Measurement range: COD calibrated with KHP: 0-1000 mg/L COD (5 mm path); 0-100 mg/L COD (25 mm path); turbidity: 10-1000 NTU or 10-300 NTU
- Accuracy: COD: ±5% or ±1 mg/L with KHP standard solution, whichever is greater; turbidity: ±10%
- Repeatability: ±5% with KHP standard solution
- Resolution: COD: 0.01 mg/L; turbidity: 0.01 NTU
- Pressure range: ≤0.1 MPa
- Sensor material: SUS316L body for standard version; titanium alloy for seawater version; PUR cable
- Sensor size: 34 x 223 mm (5 mm path); 34 x 244 mm (25 mm path)
- Sensor weight: 0.8 kg
- Sensor protection: IP68 / NEMA6P
- Power supply: AC 85-500 VAC; DC 9-36 VDC
- Output: 3-channel 4-20 mA
- Relay: Three relays with configurable response parameters
- Communication: MODBUS RS485
- Storage temperature: -15 to 60°C
- Operating temperature: 0-45°C, non-freezing
- Transmitter size: 145 x 125 x 162 mm (L x W x H)
- Transmitter weight: 1.35 kg
- Transmitter protection: IP66 / NEMA4X
- Cable length: 10 m standard cable; extendable to 100 m unless otherwise noted
Applications
- Continuous organic load monitoring in wastewater treatment processes
- Real-time wastewater quality monitoring at influent, effluent, surface water, and industrial discharge points
- Wastewater treatment applications
- Drinking water applications
- Surface water applications
- Industrial process water applications
- Aquaculture applications
- Environmental monitoring applications
Benefits
- UV absorbance method for organic matter and COD/BOD correlation
- Direct immersion measurement without sampling or reagent dosing
- Fast response time for continuous measurement
- Automatic cleaning option helps reduce maintenance
- Reverse-polarity protection, RS485 protection, data storage, and optional wireless module
Frequently asked questions
What does the PUVCOD-600 measure?
PUVCOD-600 is configured for Measurement range: COD calibrated with KHP: 0-1000 mg/L COD (5 mm path); 0-100 mg/L COD (25 mm path); turbidity: 10-1000 NTU or 10-300 NTU; Accuracy: COD: ±5% or ±1 mg/L with KHP standard solution, whichever is greater; turbidity: ±10%; Repeatability: ±5% with KHP standard solution; Resolution: COD: 0.01 mg/L; turbidity: 0.01 NTU.
Where is the PUVCOD-600 used?
Typical applications include Continuous organic load monitoring in wastewater treatment processes, Real-time wastewater quality monitoring at influent, effluent, surface water, and industrial discharge points, Wastewater treatment applications, Drinking water applications.
How do I select or order the PUVCOD-600?
Send FUNEL your target parameters, measuring range, water type, quantity and application. We will confirm the configuration and provide a quotation and datasheet.
