PLTU-600 Low Range Turbidity Online Analyzer
Model: PLTU-600
Integrated low-range turbidity analyzer with EPA 90-degree scattering method for filtered water and drinking water systems.
PLTU-600
Integrated low-range turbidity analyzer with EPA 90-degree scattering method for filtered water and drinking water systems.
Best for: Turbidity monitoring at filter outlet, clean water outlet, drinking water, seawater, and purified water stages, Low-range turbidity monitoring for industrial circulating cooling water, permeate water, and reclaimed water systems, Wastewater treatment applications.
Specifications
- Measurement range: 0.001-100 NTU
- Accuracy: 0.001-40 NTU: ±2% of reading or ±0.015 NTU, whichever is greater; 40-100 NTU: ±5%
- Repeatability: ≤2%
- Resolution: 0.001-0.1 NTU depending on measuring range
- Display: 3.5-inch LCD display
- Sample flow: 200 mL/min ≤ X ≤ 400 mL/min
- Pipe connection: Quick-connect inlet, outlet, and drain fittings
- Calibration: Sample calibration; slope calibration
- Sensor material: ASA body; PUR cable
- Power supply: Sensor: 9-36 VDC; optional 220 VAC to 12 VDC adapter
- Output: 1-channel 4-20 mA
- Relay: 1 relay
- Communication: MODBUS RS485
- Storage temperature: -15 to 60°C
- Operating temperature: 0-45°C, non-freezing
- Size: 158 x 166.2 x 155 mm (L x W x H)
- Weight: 1 kg
- Protection: IP65 indoor
Applications
- Turbidity monitoring at filter outlet, clean water outlet, drinking water, seawater, and purified water stages
- Low-range turbidity monitoring for industrial circulating cooling water, permeate water, and reclaimed water systems
- Wastewater treatment applications
- Drinking water applications
- Surface water applications
- Industrial process water applications
- Aquaculture applications
- Environmental monitoring applications
Benefits
- EPA 90-degree scattering method for low-range turbidity monitoring
- Stable data output with good repeatability
- Simple cleaning and maintenance
- Reverse-polarity protection and RS485 protection
- Compact indoor design for water plant panels and sampling systems
Frequently asked questions
What does the PLTU-600 measure?
PLTU-600 is configured for Measurement range: 0.001-100 NTU; Accuracy: 0.001-40 NTU: ±2% of reading or ±0.015 NTU, whichever is greater; 40-100 NTU: ±5%; Repeatability: ≤2%; Resolution: 0.001-0.1 NTU depending on measuring range.
Where is the PLTU-600 used?
Typical applications include Turbidity monitoring at filter outlet, clean water outlet, drinking water, seawater, and purified water stages, Low-range turbidity monitoring for industrial circulating cooling water, permeate water, and reclaimed water systems, Wastewater treatment applications, Drinking water applications.
How do I select or order the PLTU-600?
Send FUNEL your target parameters, measuring range, water type, quantity and application. We will confirm the configuration and provide a quotation and datasheet.
