PPH-500F Industrial pH Sensor
Model: PPH-500F
Industrial pH sensor series for sewage, boiler water, chemical, high-temperature, high-pressure, and fluoride-containing water conditions.
PPH-500F
Industrial pH sensor series for sewage, boiler water, chemical, high-temperature, high-pressure, and fluoride-containing water conditions.
Best for: Sewage treatment, conventional industrial water, and boiler water pH monitoring, Chemical, printing and dyeing, high organic matter, high temperature, high pressure, and high salt water conditions, Semiconductor, food and beverage, chlorine-containing, heavy metal, sulfide, and alkaline wastewater applications.
Specifications
- Measurement range: 0-14 pH
- Temperature range: Standard: 0-100°C; high temperature: 0-130°C; low temperature: -15-80°C
- Pressure range: 0-3 bar; 8 bar max
- Temperature element: PT1000
- Output slope: >95%
- Zero potential: 7 ±0.25 pH
- Response time: <30 s
- Body material: Glass electrode; holder material options: ABS, PPS, PTFE
- Protection: IP68
- Cable length: 10 m standard; extendable to 50 m
Applications
- Sewage treatment, conventional industrial water, and boiler water pH monitoring
- Chemical, printing and dyeing, high organic matter, high temperature, high pressure, and high salt water conditions
- Semiconductor, food and beverage, chlorine-containing, heavy metal, sulfide, and alkaline wastewater applications
- Wastewater treatment applications
- Drinking water applications
- Surface water applications
- Industrial process water applications
- Chemical process applications
- Environmental monitoring applications
Benefits
- Good repeatability and stability for demanding industrial water applications
- Double liquid junction structure with strong anti-pollution capability and high temperature resistance
- IP68 waterproof rating for online installation
- Sensitive glass bulb with strong mechanical impact resistance
- Multiple body materials and electrode types for different water conditions
Frequently asked questions
What does the PPH-500F measure?
PPH-500F is configured for Measurement range: 0-14 pH; Temperature range: Standard: 0-100°C; high temperature: 0-130°C; low temperature: -15-80°C; Pressure range: 0-3 bar; 8 bar max; Temperature element: PT1000.
Where is the PPH-500F used?
Typical applications include Sewage treatment, conventional industrial water, and boiler water pH monitoring, Chemical, printing and dyeing, high organic matter, high temperature, high pressure, and high salt water conditions, Semiconductor, food and beverage, chlorine-containing, heavy metal, sulfide, and alkaline wastewater applications, Wastewater treatment applications.
How do I select or order the PPH-500F?
Send FUNEL your target parameters, measuring range, water type, quantity and application. We will confirm the configuration and provide a quotation and datasheet.
