POP-500B Digital ORP Sensor
Model: POP-500B
Digital ORP sensor with RS485 Modbus output for ±2000 mV online oxidation-reduction potential monitoring.
POP-500B
Digital ORP sensor with RS485 Modbus output for ±2000 mV online oxidation-reduction potential monitoring.
Best for: Digital ORP monitoring in disinfection, oxidation, reduction, and chemical dosing processes, Online redox measurement for wastewater, process water, and environmental monitoring systems, Wastewater treatment applications.
Specifications
- Measured parameter: ORP
- Main material: 316L stainless steel housing; PUR cable
- Measurement range: ±2000 mV
- Resolution: 0.1 mV
- Accuracy: ±5 mV
- Repeatability: ±2 mV
- Electrode pressure: 0-0.1 MPa
- Electrode temperature: 0-45°C, non-freezing
- Power supply: 9-36 VDC
- Communication: RS485, standard Modbus protocol
- Protection: IP68 / NEMA6P
- Size: 34 x 230 mm (diameter x length)
- Cable length: 10 m standard; extendable to 100 m
Applications
- Digital ORP monitoring in disinfection, oxidation, reduction, and chemical dosing processes
- Online redox measurement for wastewater, process water, and environmental monitoring systems
- Wastewater treatment applications
- Drinking water applications
- Surface water applications
- Industrial process water applications
- Chemical process applications
- Environmental monitoring applications
Benefits
- Digital ORP output for direct integration with automation systems
- 316L stainless steel housing and PUR cable
- RS485 standard Modbus communication
- 9-36 VDC power supply with reverse-polarity and communication protection
- IP68 / NEMA6P protection for online field installation
Frequently asked questions
What does the POP-500B measure?
POP-500B is configured for Measured parameter: ORP; Main material: 316L stainless steel housing; PUR cable; Measurement range: ±2000 mV; Resolution: 0.1 mV.
Where is the POP-500B used?
Typical applications include Digital ORP monitoring in disinfection, oxidation, reduction, and chemical dosing processes, Online redox measurement for wastewater, process water, and environmental monitoring systems, Wastewater treatment applications, Drinking water applications.
How do I select or order the POP-500B?
Send FUNEL your target parameters, measuring range, water type, quantity and application. We will confirm the configuration and provide a quotation and datasheet.
